Geliss freeze dryer machine for candy
HFD-20
Brand Name: Geliss
Certification: CE
Minimum Order Quantity: 1 Unit
Price: Available Upon Request
Packaging Details: Plywood Case
Delivery Time: 7-30 Working Days
Payment Terms: T/T
Supply Ability: 300 Units/Month
Certification: CE
Minimum Order Quantity: 1 Unit
Price: Available Upon Request
Packaging Details: Plywood Case
Delivery Time: 7-30 Working Days
Payment Terms: T/T
Supply Ability: 300 Units/Month
Quantity:
Recommend Products
Geliss small freeze dryer for homeBrand Name: Geliss Certification: CE Minimum Order Quantity: 1 Unit Price: Available Upon Request Packaging Details: Plywood Case Delivery Time: 7-30 Working Days Payment Terms: T/T Supply Ability: 300 Units/MonthHFD-1
Geliss Freeze Dryer for home and fruitsBrand Name: Geliss Certification: CE Minimum Order Quantity: 1 Unit Price: Available Upon Request Packaging Details: Plywood Case Delivery Time: 7-30 Working Days Payment Terms: T/T Supply Ability: 300 Units/MonthHFD-4
Geliss food freeze dryer for homeBrand Name: Geliss Certification: CE Minimum Order Quantity: 1 Unit Price: Available Upon Request Packaging Details: Plywood Case Delivery Time: 7-30 Working Days Payment Terms: T/T Supply Ability: 300 Units/MonthHFD-6
Geliss Home Freeze Dryer for ProduceBrand Name: Geliss Certification: CE Minimum Order Quantity: 1 Unit Price: Available Upon Request Packaging Details: Plywood Case Delivery Time: 7-30 Working Days Payment Terms: T/T Supply Ability: 300 Units/MonthHFD-8
Product Overview
The HFD-20 is a medium-sized commercial freeze dryer. Unlike smaller units, it boasts a processing capacity of 26–28 kg per batch, features six food-grade stainless steel trays, and comes with 15 built-in freeze-drying programs (comprising 5 presets and 10 customizable options). This unit combines the affordability of home models with the high-volume processing capabilities of commercial equipment; whether you wish to preserve seasonal fruits or require reliable equipment to support a small business, the HFD-20 delivers consistent, high-quality low-temperature vacuum drying results.
Key Features
This freeze dryer features a spacious drying area of 2.16 square meters and can process up to 28 kg of fresh ingredients. Equipped with six food-grade stainless steel trays and an intelligent PLC control system, it offers simple and convenient operation, allowing even beginners to quickly master freeze-drying technology.
What You Can Make
If you are looking for a way to preserve surplus fresh fruit at home or are planning to start a small business, this machine is the ideal choice. The Geliss HFD-20 freeze dryer handles almost any ingredient with ease—from apples, bananas, tomatoes, and durian to various meat products.
Technical Specifications
| MODEL | HFD-1 | HFD-4 | HFD-6 | HFD-8 | HFD-15 | HFD-20 | HFD-25 | HFD-30 | HFD-50 |
|---|---|---|---|---|---|---|---|---|---|
| Freeze dried area | 0.1㎡ | 0.4㎡ | 0.6㎡ | 0.92㎡ | 1.45㎡ | 2.16㎡ | 2.52㎡ | 3㎡ | 4.95㎡ |
| Cold trap temperature | -35°C (Customizable to -50°C or -80°C) | -60℃ | -55℃ | ||||||
| processing capacity | 1-2KG/batch | 4-6KG/batch | 6-8KG/batch | 10-12KG/batch | 18-20KG/batch | 26-28KG/batch | 32-35KG/batch | 40-42KG/batch | 75KG/batch |
| Ultimate vacuum | Below 2Pa | ||||||||
| Material tray size | 145*275(mm) | 200*425(mm) | 315*430(mm) | 265*430(mm) | 265*780(mm) | 400*900(mm) | 400*900(mm) | 420*898(mm) | 500mm*550mm |
| Number of material trays | 3 pieces | 4 pieces | 4 pieces | 8 pieces | 7 pieces | 6 pieces | 7 pieces | 8 pieces | 18 pieces |
| Material tray spacing | 43mm | 45mm | 70mm | 38mm | 43mm | 53mm | 45mm | 45mm | 47mm |
| pumping speed | 2L/S | 2L/S | 4L/S | 4L/S | 4L/S | 4L/S | 4L/S | 6L/S | 8L/S |
| Water harvesting ability | 3kg/24h | 4kg/24h | 6kg/24h | 10kg/24h | 18kg/24h | 26kg/24h | 32kg/24h | 40kg/24h | 75kg/24h |
| Operating noise | ≤60dB | ≤70dB | |||||||
| supply voltage | 220V/50HZ （Customizable 110V or 380V） | Three phase electricity 380V | |||||||
| Machine dimensions | 450*500*825 (mm) | 500* 640*900 (mm) | 680* 640*1180(mm) | 680* 640*1180(mm) | 680* 990*1180(mm) | 780* 1200*1310(mm) | 780* 1200*1310(mm) | 827* 1100*1350(mm) | 1000* 2010*1560(mm) |
| net weight | 73kg | 84kg | 125kg | 130kg | 186kg | 269kg | 279kg | 335kg | 700kg |
| Package size | 570*680*1170mm | 630* 840*1260(mm) | 820* 800*1540(mm) | 820* 800*1540(mm) | 820* 1170*1600(mm) | 910* 1400*1550(mm) | 910* 1400*1550(mm) | 940* 1290*1500(mm) | 1200* 2150*1910(mm) |
| Total weight with packaging | 113kg | 139kg | 197kg | 203kg | 281kg | 370kg | 380kg | 439kg | 901kg |
| Whole machine power | 1100W | 1500W | 2000W | 2500W | 3500W | 3800W | 4100W | 4500W | 9500KW |
Why Choose This Residential Freeze Dryer?
The HFD-20 is an ideal food freeze-dryer positioned between small-scale and industrial-grade equipment, enabling businesses to scale up production with a moderate investment. Featuring a compact footprint, ease of operation, and stable performance, it is perfectly suited for commercial freeze-dried food production.
Frequently Asked Questions
Q: How many trays does this freeze dryer come with?
A: It comes with 6 removable, food-grade stainless steel trays, capable of processing 26–28 kg of fresh ingredients per batch.
Q: Is it only for freeze-drying fruit?
A: It’s not limited to fruit; it is also suitable for vegetables, meat, herbs, baby food, and a wide range of other ingredients.
Q: Is it easy to operate?
A: Very easy. It features 15 built-in programs (5 preset + 10 customizable) and supports one-touch operation, eliminating the need for manual parameter adjustments. It also supports remote control via a mobile app.
Q: Is this home freeze dryer quiet?
A: Yes, the noise level is 55 decibels or lower—quieter than a dishwasher. It is ideal for open-plan kitchens or apartment living.
Q: Does it require professional installation?
A: No. It is a plug-and-play unit: simply unbox, plug it in, and you can start your first batch within minutes.
Act now.
A: It comes with 6 removable, food-grade stainless steel trays, capable of processing 26–28 kg of fresh ingredients per batch.
Q: Is it only for freeze-drying fruit?
A: It’s not limited to fruit; it is also suitable for vegetables, meat, herbs, baby food, and a wide range of other ingredients.
Q: Is it easy to operate?
A: Very easy. It features 15 built-in programs (5 preset + 10 customizable) and supports one-touch operation, eliminating the need for manual parameter adjustments. It also supports remote control via a mobile app.
Q: Is this home freeze dryer quiet?
A: Yes, the noise level is 55 decibels or lower—quieter than a dishwasher. It is ideal for open-plan kitchens or apartment living.
Q: Does it require professional installation?
A: No. It is a plug-and-play unit: simply unbox, plug it in, and you can start your first batch within minutes.
Act now.
Call to Action
📦 Bulk Purchasing & Customization: Contact us for exclusive wholesale quotes, one-on-one consultations, and global shipping services.
